Coaxial Ground Plane Antenna for the 144-174 MHz Band (AC-2F)
Type: Ground Plane
AC-2F is a fiberglass ground plane antenna of the triple-leg type. The antenna comprises an aluminum GPGP-head, one coaxial-fiberglass radiator and three aluminum radials. The construction of the mount makes it possible to lead the cable either inside or along the outside of the mast tube. AC-2F is made of high-quality materials and will endure for years where no maintenance is required.
Add to Inquiry Cart
Specifications
Electrical
| Frequency Range |
144-174 MHz |
| Band Width |
6 MHz |
| SWR |
< 1.5 |
| Gain |
0 dBd (2.15 dBi ) |
| Impedance |
50 Ω |
| Max Power |
300 W |
| Polarization |
Vertical |
| Antistatic Protection |
N/A |
Mechanical
| Connector |
N female or UHF female |
| Length |
0.8 m max |
| Weight |
2.6 kg |
| Mounting |
35-40 mm mast tube |
| Material |
Radiator: aluminum or stainless steel in fiberglass tube Radials: aluminum or stainless steel Mounting bracket: aluminum |
| Wind Load |
150 km/h |
