2-element Yagi antenna for the 144-174 MHz Band with 3 dBd Gain (AC-D3G)
Type: Yagi
This is a 2-element Yagi antenna with 3 dBd Gain. This Yagi incorporates baluns optimized for wide bandwidth and accurate matching. The entire balun unit and feeder cable inlet are completely sealed in a polyethylene (PET) moulding ensuring permanent waterproof connections. The antenna is terminated with N (female) connector. Radiating elements, supporting booms and adjoining metal castings are constructed in high-quality-aluminum alloys to prevent corrosion. All metal parts are DC-grounded. A mast clamp is provided for mounting on 30-50 mm diameter mast tube.
Add to Inquiry Cart
Specifications
Electrical
| Frequency Range |
144-174 MHz |
| Band Width |
15 MHz |
| SWR |
< 1.5 |
| Gain |
3 dBd (5.15 dBi) |
| Impedance |
50 Ω |
| Max Power |
150 W |
| Polarization |
Vertical; Horizontal |
| Front to back ratio |
12 dB |
| Antistatic Protection |
DC-grounded (Connector shows a DC-short) |
Mechanical
| Connector |
N female |
| Length |
0.9 m |
| Weight |
3.6 kg |
| Mounting |
30-50 mm mast tube |
| Material |
Aluminum |
| Wind Load |
150 km/h |
