4-element Yagi Antenna for the 1.2 GHz Band with 7 dBd Gain (AC1.2-7G)
Type: Yagi
This is a 4-element Yagi antenna with 7 dBd Gain. This Yagi incorporates baluns optimized for wide bandwidth and accurate matching. The antenna is terminated with N (female) connector. Radiating elements, supporting booms and adjoining metal castings are constructed in high-quality-aluminum alloys to prevent corrosion. All metal parts are DC-grounded. A mast clamp is provided for mounting on 20-40 mm diameter mast tube.
Add to Inquiry Cart
Specifications
Electrical
| Frequency Range |
1100-1300 MHz |
| Band Width |
100 MHz |
| SWR |
< 1.5 |
| Gain |
7 dBd (9.15 dBi) |
| Impedance |
50 Ω |
| Max Power |
150 W |
| Polarization |
Vertical; Horizontal |
| Front to back ratio |
16 dB |
| Antistatic Protection |
N/A |
Mechanical
| Cable type |
N female |
| Length |
0.4 m |
| Weight |
0.8 kg |
| Mounting |
20-40 mm mast tube |
| Material |
PVC-coated aluminum |
| Wind Load |
150 km/h |
