Open Dipole for the 48-66 MHz Band (AC50-D-O)
Type: Dipole
Single, 0 dBd dipole incorporating a balun optimized for wide band width and accurate matching. The dipole element, the supporting boom and the adjoining metal castings have been constructed in high quality aluminum alloys to prevent corrosion. All metal parts are not DC-grounded. The antenna is supplied with clamp for mounting on 30-50 mm diameter mast tubes.
Add to Inquiry Cart
Specifications
Electrical
| Frequency Range |
48-66 MHz |
| Band Width |
19 MHz |
| SWR |
< 1.5 |
| Gain |
0 dBd (2.15 dBi) |
| Impedance |
50 Ω |
| Max Power |
150 W |
| Polarization |
Vertical; Horizontal |
| Antistatic Protection |
N/A |
Mechanical
| Connector |
N female |
| Length |
0.8 m |
| Weight |
3.8 kg |
| Mounting |
30-50 mm mast tube |
| Material |
Aluminum |
| Wind Load |
150 km/h |
